Sculpt Axis FAS120 Panoramic Single (LIFT/SWING)

The French-made Axis FAS120 Panoramic Single is a premium landscape wood fireplace combining a wide, uninterrupted flame view with impressive 22.5 kW heating performance. Its frameless façade, black ceramic glass and cast-iron internal liners create a sophisticated centrepiece, while the lift-and-swing door provides convenient operation and maintenance.

Specifications

• Construction: Steel firebox with grooved cast-iron internal liners
• Glass: Black silk-screen printed ceramic glass
• Heat output: 22.5 kW
• Door operation: Lift and swing
• Glass viewing area: 966 mm W × 474 mm H
• Overall firebox width: Approximately 1183 mm
• Overall firebox depth: Approximately 517 mm
• Air system: High-performance airflow system
• Façade: Clean, frameless design; optional trims available
• Fire grate and ashpan: Included
• Minimum flue height: 5.4 m
• Flue sizes: 230 mm inner, 280 mm and 330 mm outer
• Outside-air kit: Optional; required for homes rated six stars or higher
• Hot-air transfer kit: Optional
• Weight: 290 kg
• Warranty: 10 years on the firebox—conditions apply
• Country of manufacture: France
